SPEC SHEET
Features
Injection-molded thermoplastic ABS housing, UL 94V-0 flame rating
Suitable for wall and ceiling mount applications
120V/277VAC dual voltage operation
Built-in 3.6V 2000mAh Nickel cadmium battery for minimum 90 minutes emergency operation
Test switch and charge indicator
Innovative, easy installation in minutes
Universal J-box mounting pattern
2*12pcs ultra bright 2835 0.5W LED lamp heads for emergency mode, provide more than 400LM output
Maximum 24 hours for full recharge time
0℃ to 40℃ indoor damp location listed
Specifications
| Product Name: | Wet Location LED Emergency Light | Packing Information | |||
| Model No.: | JLEU5WP | Packing: | White box | ||
| Main Specification: | 2*12pcs Super bright LED, 90mins, Ni-Cad 3.6V 2000mAh, wet location | Carton: | L (cm) | W (cm) | H (cm) |
| Carton Size: | 45.2 | 34 | 27.5 | ||
| Product Size: | Carton CBM: | 0.042M3 | |||
| MOQ: | 1000PCS | Q'TY/INNER BOX: | PCS | ||
| Lead Time: | 35 days | Q'TY/CTN: | 6PCS | ||
| Sample Delivery Time: | 3~10 days | Gross Weight: | 7.3KGS | ||
| Remarks: IP65, Waterproof, Outdoor, UL & cUL Listed | Net Weight: | 6.3KGS | |||
| Container Loading Q'TY (PCS): | 1*20' | 1*40' | 1*40' HQ | ||
| 3929 | 8214 | 9571 | |||

Applications

Hospital

Hotel

Mall

Office Building

Outdoor

Parking Lot

Restaurant

Station

Supermarket
Installation Video
Product Comparison
| PRICTURE | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() | ![]() |
| MODEL NO | JLEU1 | JLEU3 | JLEU4 | JLEU5 | JLEU9 | JLEU10 | JLEU12 | JLEU15 |
| Item Weight | 2.65 lbs/1.2 kgs | 1.54 lbs/0.7 kgs | 1.54lbs/0.7 kgs | 1.32 lbs/0.6 kgs | 1.65 lbs/0.75 kgs | 0.66 lbs/0.3 kgs | 1.1 lbs/0.5 kgs | 0.88lbs/0.4 kgs |
| Inner Box Size | 16.22 x 5.63 x 4.49 inches | 13.66 x 4.72 x 3.62 inches | 12.13x 5.3 x 3.15 inches | 11.22 x 4.65 x 2.95 inches | 12.4 x 5.04 x 4.13 inches | 8.86 x 4.33 x 1.97 inches | 9.69 x 4.92 x 2.48 inches | 9.57 x 4.8 x 1.97 inches |
| 41.2 x 14.3 x 11.4 cm | 34.7 x 12 x 9.2 cm | 30.8 x 13.5 x 8 cm | 28.5 x 11.8 x 7.5 cm | 31.5 x 12.8 x 10.5 cm | 22.5 x 11 x 5 cm | 24.6 x 12.5 x 6.3 cm | 24.3 x 12.2 x 5 cm | |
| Color | White | White | White | White | White | White | White | White |
| Material | Thermoplastic | Thermoplastic | Thermoplastic | Thermoplastic | Thermoplastic | Thermoplastic | Thermoplastic | Thermoplastic |
| Voltage | 120/277 Volts | 120/277 Volts | 120/277 Volts | 120/277 Volts | 120/277 Volts | 120/277 Volts | 120-277 Volts | 120-277 Volts |
| Battery | 3.6V 1000mAh Ni-Cad | 3.6V 1000mAh Ni-Cad | 3.6V 1000mAh Ni-Cad | 3.6V 1000mAh Ni-Cad | 3.6V 1000mAh Ni-Cad | 3.6V 1000mAh Ni-Cad | 3.6V 1000mAh Ni-Cad | 3.6V 1000mAh Ni-MH |
| Wattage | 3.5 watts | 2.4 watts | 3.6watts | 2.4 watts | 2.4 watts | 2 watts | 4.5 watts | 2watts |
| Type of Bulb | LED | LED | LED | LED | LED | LED | LED | LED |
| Mounting Type | Wall Mounted | Wall Mounted | Wall Mounted | Wall Mounted | Wall Mounted | Wall Mounted | Wall Mounted | Wall Mounted |
| Certifications | UL listed | UL listed | UL listed | UL listed | UL listed | UL listed | UL listed | UL listed |
| Weather Ratings | Listed for damp location | Listed for damp location | Listed for damp location | Listed for damp location | Listed for damp location | Listed for damp location | Listed for damp location | Listed for damp location |
| Carton Weight | 17.64 lbs/8 kgs | 11.02 lbs/5 kgs | 11.02lbs/5 kgs | 8.82 lbs/4 kgs | 11.46 lbs/5.2 kgs | 8.82 lbs/4 kgs | 7.72 lbs/3.5 kgs | 12.13lbs/5.5 kgs |
| Carton Size | 16.7 x 12.4 x 14.37 inches / 6pcs | 14.96 x 14.17 x 7.87 inches / 6pcs | 12.6x 11.8 x 10.24 inches/ 6pcs | 11.8 x 9.84 x 9.84 inches / 6pcs | 16 x 12.8 x 9.06 inches / 6pcs | 13.98 x 9.65 x 9.06 inches / 12pcs | 11.22 x 10.43 x 8.27 inches / 6pcs | 14.96x 10.04 x 8.86 inches/ 12pcs |
| 42.5 x 31.5 x 36.5 cm / 6pcs | 38 x 36 x 20 cm / 6pcs | 32 x 30 x 26 cm / 6pcs | 30 x 25 x 25 cm / 6pcs | 40.7 x 32.5 x 23 cm / 6pcs | 35.5 x 24.5 x 23 cm / 12pcs | 28.5 x 26.5 x 21 cm / 6pcs | 38 x 25.5 x 22.5 cm / 12pcs | |
| Charging Time | 24 Hours | 24 Hours | 24 Hours | 24 Hours | 24 Hours | 24 Hours | 24 Hours | 24 Hours |
| Emergency Run Time | ≥90Mins | ≥90Mins | ≥90Mins | ≥90Mins | ≥90Mins | ≥90Mins | ≥90Mins | ≥90Mins |
