Features

ILLUMINATION

Emergency lamps use long-lasting, energy efficient ultra bright white LEDs. Heads are made with high-performance chromeplated reflectors and polycarbonate lenses for optimal light distribution.

MULTI-ANGLE LIGHTING

Each side of the emergency light has bright adjustable floodlights on the sign for maximum visibility. 360° ratation, the flexibility of the light direction allows you to point the lights at almost a 90 degree angle.

EMERGENCY POWER BATTERY BACKUP

Emergency light built-in 3.6V 1000mAh Nickel cadmium backup battery, upon failure of the normal utility power, an internal solidstate transfer switch automatically provides uninterrupted emergency operation for at least 90 minutes.

EASY INSTALLATION IN MINUTES

Can be wall or ceiling mounted, universal J-box mounting pattern. Test switch and status indicator let you know the emergency lights has power and the battery is working.

REMOTE HEAD CAPABLE OPTION

The remote head capability option allows the unit to supply power to up to two additional 3.6V LED remote heads. The remote heads would then operate on the same emergency mode as the standard units.

5 YEAR WARRANTY

Our LED emergency lights are offered high quality products at affordable prices backed by 5 year warranty and professional after-sales support.

Specifications

Applications

Hospital

Hotel

Mall

Office Building

Outdoor

Parking Lot

Restaurant

Station

Supermarket

Installation Video

Product Comparison

PRICTURE
MODEL NO	JLEU1	JLEU3	JLEU4	JLEU5	JLEU9	JLEU10	JLEU12	JLEU15
Item Weight	2.65 lbs/1.2 kgs	1.54 lbs/0.7 kgs	1.54lbs/0.7 kgs	1.32 lbs/0.6 kgs	1.65 lbs/0.75 kgs	0.66 lbs/0.3 kgs	1.1 lbs/0.5 kgs	0.88lbs/0.4 kgs
Inner Box Size	16.22 x 5.63 x 4.49 inches	13.66 x 4.72 x 3.62 inches	12.13x 5.3 x 3.15 inches	11.22 x 4.65 x 2.95 inches	12.4 x 5.04 x 4.13 inches	8.86 x 4.33 x 1.97 inches	9.69 x 4.92 x 2.48 inches	9.57 x 4.8 x 1.97 inches
	41.2 x 14.3 x 11.4 cm	34.7 x 12 x 9.2 cm	30.8 x 13.5 x 8 cm	28.5 x 11.8 x 7.5 cm	31.5 x 12.8 x 10.5 cm	22.5 x 11 x 5 cm	24.6 x 12.5 x 6.3 cm	24.3 x 12.2 x 5 cm
Color	‎White	‎White	‎White	‎White	‎White	‎White	‎White	‎White
Material	Thermoplastic	Thermoplastic	Thermoplastic	Thermoplastic	Thermoplastic	Thermoplastic	Thermoplastic	Thermoplastic
Voltage	120/277 Volts	120/277 Volts	120/277 Volts	120/277 Volts	120/277 Volts	120/277 Volts	120-277 Volts	120-277 Volts
Battery	3.6V 1000mAh Ni-Cad	3.6V 1000mAh Ni-Cad	3.6V 1000mAh Ni-Cad	3.6V 1000mAh Ni-Cad	3.6V 1000mAh Ni-Cad	3.6V 1000mAh Ni-Cad	3.6V 1000mAh Ni-Cad	3.6V 1000mAh Ni-MH
Wattage	3.5 watts	2.4 watts	3.6watts	2.4 watts	2.4 watts	2 watts	4.5 watts	2watts
Type of Bulb	‎LED	‎LED	‎LED	‎LED	‎LED	‎LED	‎LED	‎LED
Mounting Type	‎Wall Mounted	‎Wall Mounted	‎Wall Mounted	‎Wall Mounted	‎Wall Mounted	‎Wall Mounted	‎Wall Mounted	‎Wall Mounted
Certifications	UL Listed	UL Listed	UL Listed	UL Listed	UL Listed	UL Listed	UL Listed	UL Listed
Weather Ratings	Listed for damp location	Listed for damp location	Listed for damp location	Listed for damp location	Listed for damp location	Listed for damp location	Listed for damp location	Listed for damp location
Carton Weight	17.64 lbs/8 kgs	11.02 lbs/5 kgs	11.02lbs/5 kgs	8.82 lbs/4 kgs	11.46 lbs/5.2 kgs	8.82 lbs/4 kgs	7.72 lbs/3.5 kgs	12.13lbs/5.5 kgs
Carton Size	16.7 x 12.4 x 14.37 inches / 6pcs	14.96 x 14.17 x 7.87 inches / 6pcs	12.6x 11.8 x 10.24 inches/ 6pcs	11.8 x 9.84 x 9.84 inches / 6pcs	16 x 12.8 x 9.06 inches / 6pcs	13.98 x 9.65 x 9.06 inches / 12pcs	11.22 x 10.43 x 8.27 inches / 6pcs	14.96x 10.04 x 8.86 inches/ 12pcs
	42.5 x 31.5 x 36.5 cm / 6pcs	38 x 36 x 20 cm / 6pcs	32 x 30 x 26 cm / 6pcs	30 x 25 x 25 cm / 6pcs	40.7 x 32.5 x 23 cm / 6pcs	35.5 x 24.5 x 23 cm / 12pcs	28.5 x 26.5 x 21 cm / 6pcs	38 x 25.5 x 22.5 cm / 12pcs
Charging Time	24 Hours	24 Hours	24 Hours	24 Hours	24 Hours	24 Hours	24 Hours	24 Hours
Emergency Run Time	≥90Mins	≥90Mins	≥90Mins	≥90Mins	≥90Mins	≥90Mins	≥90Mins	≥90Mins

FAQ

What is the battery runtime of this UL approved twin head LED emergency light after full charge?

This twin head emergency light delivers a minimum 90-minute rated runtime. Its lead-acid battery supports automatic charging and low-voltage protection to extend service life.

Does this UL twin head LED emergency light meet UL standard requirements for fire-rated exit applications?

Our twin head LED emergency light passes UL certification. Its housing and circuit design comply with relevant safety standards for indoor commercial emergency lighting installations.

How long is the lead time for mass production of UL approved twin head LED emergency lights once deposit is received?

Mass production lead time is around 25–30 working days after deposit confirmation. We conduct full UL standard testing before shipment to guarantee product consistency.

Can this UL approved twin head LED emergency light work normally during AC power failure for commercial building projects?

Yes. It will automatically switch to battery power once mains power cuts off. The two adjustable LED heads offer wide illumination coverage for building emergency evacuation.

Are replacement spare parts like batteries and LED heads available separately for the UL twin head emergency light after installation?

We supply matching replacement batteries and LED heads. All spare parts follow UL specifications, helping customers maintain emergency lights and prolong the whole unit service cycle.
