This new slim emergency light features a clear polycarbonate diffuser and ABS housing, with side-mounted LEDs for smooth display. Equipped with a 3.6V 1000mAh Ni-Cad or 4V 2.5Ah sealed lead-acid battery, it supports 3 hours of maintained operation and complies with IEC60598-2-22 and RoHS standards.
Features
New slim type emergency light
Clear polycarbonate diffuser & ABS housing
Led located on the side make the display smooth.
3 hours maintained operation
Optional multi directional sticker legend kit
Complies with IEC60598-2-22, ROSH
SLIM DESIGN
Compact and sleek, suitable for various installation settings.
BRIGHT LEDS
20pcs SMD LED2835, delivering 85 lumens of bright light.
LONG-LASTING BATTERY
Supports 3 hours of maintained operation with a 24-hour recharge time.
ECO-FRIENDLY COMPLIANCE
Meets IEC60598-2-22 and RoHS standards for safety and reliability.
MULTI-DIRECTIONAL STICKER KIT
Optional stickers for flexible labeling.
Specifications
| Product Name: | Emergency Light | Packing Information | |||
| Model No.: | LE511AD | Packing: | Color box | ||
| Main Specification: | 20PCS SMD2835 LED,3.6V 1000MAH Ni-Cad battery | Carton: | L(cm) | W(cm) | H(cm) |
| Carton Size: | 38 | 32 | 25.5 | ||
| Product Size: | 292x102x53mm | Carton CBM: | 0.031M3 | ||
| MOQ: | 1000PCS | Q'TY/INNER BOX: | PCS | ||
| Lead Time: | 35 days | Q'TY/CTN: | 12PCS | ||
| Sample Delivery Time: | 3~10 days | Gross Weight: | 7.6KGS | ||
| Remarks: Maintained, W/O recessed box | Net Weight: | 7KGS | |||
| Container Loading Q'TY (PCS): | 1*20' | 1*40' | 1*40' HQ | ||
| 10645 | 22258 | 25935 | |||
| Mode of operation | Maintained | Voltage | 220-240V 50-60Hz |
| Power | 3.8W max | Output Voltage | DC 6V |
| Output Power | 0.7W | Lumen Output | 85lm |
| Battery | 3.6V 1000mAh Ni-Cad battery or 4V2.5AH sealed lead-acid battery | Max Charge Current(mA) | 400mA |
| Max Discharge Current(mA) | 280mA | Charging Time | 24H |
| Discharging Time | 3H | Lamp | SMD LED2835*20pcs |
| IP Grade | IP20 |
Applications
Hospital
Hotel
Mall
Office Building
Outdoor
Parking Lot
Restaurant
Station
Supermarket
